比亞迪漢DMI/EV中置升降喇叭
MidVoiceCoil2"(50mm)MaterialCeramics+ALFrequencyResponse500Hz-15kHzDCResist
| Mid Voice Coil | 2 "( 50mm) |
| Material | Ceramics + AL |
| Frequency Response | 500Hz-15kHz |
| DC Resistance | 4ohms |
| Voice Coil inductance | 0.015 mH |
| Resonance Frequency | 430Hz |
| Sensitivity ( 2.83V/1m) | 92dB |
| Power | 25W |
| Tweeter Voice Coil | 0.75 "( 20.4mm) |
| Material | Ceramics + AL |
| Frequency Response | 1500Hz-20kHz |
| DC Resistance | 4ohms |
| Voice Coil inductance | 0.003 mH |
| Resonance Frequency | 1460Hz |
| Sensitivity ( 2.83V/1m) | 88dB |
| Power | 10W |
