150W X4CH 晶封管汽車功放
150 W x 4 CH AB Amplifier ( Crystal Sealed tube)
150 W x 4 CH AB Amplifier ( Crystal Sealed tube)
Specifications:
| Rated output power 4ohm | 100W X 4CH |
| Rated output power 2ohm | 120W X 4CH |
| Frequency Response | 5Hz-50kHz |
| Input Sensitivity | 150mV-6V |
| Input Impendance | 10k |
| Output Load resistance | 2Ohm- 8 Ohm |
| Channel seperation | >=-60dB |
| Total Harmonic distortion | =< 0.05% |
| Signal to nise ratio | >=90dB |
| Standby current | =< 1A |
| Sixe(excluding packing material ) | 395mmx 190mm x46mm |
We follow the principle of in developing continuously optimized. Therefor if parameters and the design of the all the products are subjuect to cahnge without prior notice.
